Driver IC:SSD1315
Interface: Parallel/I2C/ 4-wire SPI
Color options:Blue/White
1.2 Mechanical Specifications
1) Outline Drawing: According to the annexed outline drawing
2) Number of Pixels: 128 x 64
3) Panel Size: 24.7 x 16.6 x 1.3 (mm)
4) Active Area: 21.74 x11.175 (mm)
5) Pixel Pitch: 0.17 x 0.175 (mm)
6) Pixel Size: 0.15 x 0.15 (mm)
