0.99" 0.99inch GC9107 SPI 128RGBx115 Round Lcd Displays TFT Screen Display LCD Module Circular Display
- Overview
- Recommended Products
1 LCD Size:0.99 inch(Diameter) -
2 Display Mode: Normally black -
3 Resolution: 128(H)RGB x 115(V) -
4 Dot pitch: 0.19(H) x 0.19(V) mm -
5 Active area: 24.36096*21.8868mm -
6 Module size: 26.71(H) x 26.22(V) x1.86(D) mm -
7 Color arrangement: RGB Vtertical stripe -
8 Interface: SPI 4 Interface -
9 Drive IC GC9107
10 Luminance(cd/m2): 450 (TYP)
11 Viewing Direction: All View
12 Backlight: 2 White LED
13 Operating Temp.:-20℃~ + 70℃
14 Storage Temp.-30℃~+ 80℃℃
15 Weight 1.2g
