Driver IC:SSD1312
Interface: I²C
Color options:Blue/White
Display Specifications
1) Display Mode: Passive Matrix
2) Display Color: Monochrome (White)
3) Drive Duty: 1/16 Duty
Mechanical Specifications
1) Outline Drawing: According to the annexed outline drawing
2) Number of Pixels: 96 x 16
3) Panel Size: 24 x 6.9x 1.25 (mm)
4) Active Area: 17.26 x3.18 (mm)
5) Pixel Pitch: 0.18x 0.2 (mm)
6) Pixel Size: 0.16 x 0.18 (mm)
