Driver IC:SSD1306/ SSD1315
Interface: I²C
Color options:White
Display Specifications
1) Display Mode: Passive Matrix
2) Display Color: Monochrome (White/Blue)
3) Drive Duty: 1/16 Duty
Mechanical Specifications
1) Outline Drawing: According to the annexed outline drawing
2) Number of Pixels: 96 x 16
3) Panel Size: 26.3 x 8x 1.2 (mm)
4) Active Area: 17.26 x3.18 (mm)
5) Pixel Pitch: 0.18 x 0.2 (mm)
6) Pixel Size: 0.16 x 0.18 (mm)
