1.32'' 1.32inch round TFT LCD Display Module 450 Brightness round QSPI Interface GC9C01 Driver without TP
- Overview
- Recommended Products
1 LCD Size: 1.32 inch
2 Display Mode: Normally black
3 Resolution: 360(H)RGB x360(V) pixels
4 Pixel pitch: 0.093(H) x 0.093(V) mm
5 Active area: Ø33.48 mm
6 Module size :35.98(H) x 38.54(V) x1.56 (D) mm
7 Pixel arrangement: RGB Vertical stripe -
8 Interface: QSPI -
9 Display Colors :16.7M colors
10 Drive IC: GC9C01 -
11 Luminance(cd/m2): 450 (TYP) Cd/m2
12 Viewing Direction: All View Best image
13 Backlight :2 White LED Parallel -
14 Operating Temp.:-20℃~ + 70℃℃
15 Storage Temp.:-30℃~+ 80℃
16 Weight :3.4 g
