1 LCD Size: 1.39 inch
2 Display Mode: Normally black -
3 Resolution: 360(H)RGB x360(V) pixels
4 Pixel pitch: 0.09807(H) x 0.09807(V) mm
5 Active area: Ø35.3052 mm
6 Module size: 37.80(H) x 39.77(V) x1.48 (D) mm
7 Pixel arrangement :RGB Vertical stripe -
8 Interface :QSPI
9 Display Colors: 16.7M colors
10 Drive IC: GC9B71 -
11 Luminance(cd/m2): 600 (TYP) Cd/m2
12 Viewing Direction :All View Best image
13 Backlight 3 White LED Parallel -
14 Operating Temp.
-20℃~ + 70℃℃
15 Storage Temp.-30℃~+ 80℃
16 Weight 3.8 g
