1 LCM Size 1.45 inch
2 Display Mode Normally black -
3 Resolution 412(H)RGB x412(V) pixels
4 Pixel pitch 0.0897(H) x 0.0897(V) mm
5 Active area Ø36.9564 mm
6 Module size 39.36(H) x 41.53(V) x1.56 (D) mm
7 Pixel arrangement RGB Vertical stripe -
8 LCM Interface QSPI -
9 Display Colors 16.7M colors
0 LCM Drive IC SPD2010 -
11 Luminance(cd/m2) 450 (TYP) Cd/m2
12 Viewing Direction All View Best image
13 Backlight 3 White LED Parallel -
14 Operating Temp.
-20℃~ + 70℃
℃
15 Storage Temp.
-30℃~+ 80℃
℃
16 Weight 4.3 g
