Driver IC:SSD1312
Interface:SPI/I2C
Color options:Blue/White
1.2 Mechanical Specifications
1) Outline Drawing: According to the annexed outline drawing
2) Number of Pixels: 128 x 32
3) Panel Size: 29 x 8.8 x 1.22 (mm)
4) Active Area: 22.38 x 5.58 (mm)
5) Pixel Pitch: 0.175 x 0.175 (mm)
6) Pixel Size: 0.155 x 0.155 (mm)
