1 LCD Size :0.99 inch(Diagonal) -
2 Display Mode:Normally black -
3 Resolution: 40(H)RGB x 160(V) -
4 Dot pitch: 0.1524(H) x 0.1524(V) mm -
5 Active area :6.096(H) x 24.384(V) mm -
6 Module size :8.6(H) x 29.8(V) x1.5(D) mm -
7 Color arrangement :RGB Vtertical stripe -
8 Interface: SPI4 LINE
9 Drive IC GC9D01
10Luminance(cd/m2):400
11 Viewing Direction :All View
12 Backlight: 1 White LED
13 Operating Temp.-20℃~ + 70℃
14 Storage Temp.-30℃~+ 80℃
