Driver IC:SSD1309/SH1106
Interface:8-bit 68xx/80xx Parallel,3/4-wire SPI, I²C
Color options:Blue/White/Yellow
1.1 Display Specifications
1) Display Mode: Passive Matrix
2) Display Color: Monochrome (White/Blue/Yellow)
3) Drive Duty: 1/64 Duty
1.2 Mechanical Specifications
1) Outline Drawing: According to the annexed outline drawing
2) Number of Pixels: 128 × 64
3) Panel Size: 42.04 × 27.22 × 1.45 (mm)
4) Active Area: 35.052 × 17.516 (mm)
5) Pixel Pitch: 0.274 × 0.274 (mm)
6) Pixel Size: 0.254 × 0.254 (mm)
7) Weight: 3.28 (g)
