Driver IC:SH1108
Interface:Parallel/I²C/4-wireSPI
Color options:White
1.1 Display Specifications
1) Display ModePassive Matrix
2) Display Color:Monochrome (White)
3) Drive Duty:1/128 Duty
1.2 Mechanical Specifications
1) Outline Drawing:According to the annexed outline drawing
2) Number of Pixels:128 x 160
3) Panel Size:34.5 x 48.8 x 1.4 (mm)
4) Active Area:28.908 x39.34 (mm)
5) Pixel Pitch:0.226 x 0.246 (mm)
6) Pixel Size:0.206 x 0.226 (mm
