- Overview
- Recommended Products
1 LCD Size:1.28 inch(Diameter) -
2 Display Mode Normally black -
3 Resolution 240(H)RGB x 240(V) -
4 Dot pitch 0.135(H) x 0.135(V) mm -
5 Active area:φ32.4 mm
6 Module size: 35.6(H) x 38.1(V) x1.6(D) mm -
7 Color arrangement ：RGB Vtertical stripe -
8 Interface ：8-bit Parallel MCU Interface -
9 Drive IC： GC9A01 -
10 Luminance(cd/m2)： 400 (TYP)
11 Viewing Direction： All View
12 Backlight ：2 White LED
13 Operating Temp.：-20℃~ + 70℃
14 Storage Temp.-30℃~+ 80℃
15 Weight 1.2 g
