Dot Matrix: 206 (W) x 36 (H)
Dot Size:0.29 (W) x 0.29 (H)
Dot Pitch:0.31 (W) x 0.31 (H)mm
Active Area:63.84 (W) x 11.14 (H)mm2
Panel Size:70.77 (W) x 15.14 (H)mm2
Panel Thickness:1.62 ± 0.1mm
Module Size:108.77 (W) x 15.14 (H) x 1.827 (D)mm3
Diagonal A/A size:2.55inch
FEATURES
‐ Small molecular organic light emitting diode.
‐ Color : White
‐ Panel matrix : 206x36
‐ Driver IC : SSD1362
‐ Excellent quick response time.
‐ Extremely thin thickness for best mechanism design : 1.827mm
‐ High contrast : 10,000:1
‐ Wide viewing angle : 160
‐ 3/4 wire Serial Peripheral Interface、I 2C Interface.
‐ Strong environmental resistance
‐ Wide range of operating temperature : -40 to 70°C
‐ Anti-glare polarizer
