1LCD Size:3.45”inch
2Panel Type:IPS
3Resolution :320RGBx240
4Display Mode:Normally Black
5:Number of Colors:16.7M
6Viewing Direction :80/80/80/80
7NTSC:60%
8Contrast Ratio :1200
9Luminance:300cd/m2
10 Module Size:76.90(H)x63.90(V)x3.2(D)mm
11 Panel Active Area :70.08x52.56mm
12 Pixel Pitch:1P1Dmm
13 Pixel Arrangement:RGB-stripe
15 Driver IC:ST7272A
17 Light Source :6-LED light
18 Interface :RGB 24BIT
19Operating Temperature:-20~+70℃
Storage Temperature:-30~+80℃
