LCM outline size:74.66 (H) x76.54 (V)mm
Active area:71.14 (H) x 69.82 (V)mm
Number of pixels:320(H)X480(V)
Pixel arrangement:RGB stripe
Pixel Pitch:0.2223(H) × 0.2182 (V)mm
Display color:262K-color
Viewing direction:ALL
Controller / Driver:ST7796S
Data interface:SPI/MCU
Backlight:
10 White LEDs In Parallels
