Driver IC:SSD1306
Interface:SPI
Color options:Blue/White
1) Outline Drawing : According to the annexed outline drawing
2) Number of Pixels : 128 × 32
3) Module Size : 40.50 × 11.50 × 1.20 (mm)
4) Panel Size : 30.00 × 11.50 × 1.20 (mm) including “Anti-Glare polarizer”
5) Active Area : 22.384 × 5.584 (mm)
6) Pixel Pitch : 0.175 × 0.175 (mm)
7) Pixel Size : 0.159 × 0.159 (mm)
8) Weight : 0.89 (g) ± 10%
