1 LCD Size 1.8 inch
2 Display Mode Normally black
3 Resolution 360(H)RGB x360(V) pixels
4 Pixel pitch 0.1269(H) x 0.1269(V) mm
5 Active area Ø45.684 mm
6 Module size 48.08(H) x 49.95(V) x1.92 (D) mm
7 Pixel arrangement RGB Vertical stripe -
8 Interface QSPI -
9 Display Colors 262K colors
10 Drive IC ST77916 -
11 Luminance(cd/m2) 400 (TYP) Cd/m2
12 Viewing Direction All View Best image
13 Backlight 3 White LED Parallel -
14 Operating Temp.-20℃~ + 70℃
15 Storage Temp.-30℃~+ 80℃℃
16 Weight 7.6 g
